Renogy One – M1


SKU: RMS-LP4-AUD Category:

Introducing the Renogy ONE M1, an all-in-one energy monitoring and off-grid smart living center that can revolutionized the way you experience comfort in your touring setup. The Renogy ONE M1 serves as the heart of your off-grid system and comes equipped with a sleek and flush-mount touchscreen.

With its 4″ HD display, you can now monitor every Renogy device in your home from one screen, making it convenient and easy to keep track of your energy consumption. Additionally, with the DC Home app, you can access the same system monitoring capabilities on your smartphone, giving you the freedom to monitor your off-grid system from wherever you are.

The Renogy ONE M1 allows you go “out back” without compromising on comfort. It gives you control of up to 3 devices at a time through a direct connection with panel relays. With this feature, you can create custom modes such as “Night” mode that automatically turns on lights or a “Sleep” mode that dims the lights and shuts down connected appliances.

Furthermore, Renogy ONE M1 ensures your peace of mind with its enhanced security features. The device is compatible with our Door and Window Sensors and Motion Sensors, which send instant alerts directly to your DC Home app if there is a security breach.

In summary, the Renogy ONE M1 is a comprehensive and versatile solution for off-grid living / touring, providing a simple and efficient way to monitor and manage your energy usage, control your devices, and enhance the security of your off-grid home, Caravan / Touring setup.


  • Quick View Energy Dashboard – Get rid of cumbersome cables and multiple monitors with the flush-mount Renogy ONE M1. Its 4″ HD touchscreen lets you monitor and control compatible Renogy devices in your home from one screen.
  • Control All Your Connected Devices – Panel relays of Renogy ONE M1 allow you to switch on/off up to 3 DC appliances at a time through the panel switches or the DC Home app. You can even set up different smart scenes to control devices together, depending on how you live. For instance, you can create an “Evening” mode that automatically turns on lights, or a “Sleep” mode that turns off home appliances for you.
  • Remote Energy Monitoring – Wi-Fi connectivity uploads energy data while you’re off the grid so that you can monitor your system in real time, wherever you are, with the DC Home app. You can monitor the status of batteries, charge controllers, and other connected energy devices.
Power Supply: Rated Power 3.5W
● Power Port: 8V DC-16V DC
● Type-C Port: 5V DC
Load: ≤30V DC, 5A Max Power Consumption: < 2.5W (standby)
Ports: ● USB Type-C (5V DC)
● RJ45 (CAN & RS485)
● 2-pin 2.54 mm pluggable terminal block (12V DC)
Wireless Communication ● Wi-Fi (IEEE 802.11b/g/n 2.4 GHz)
● Bluetooth 2.1/4.2 and Bluetooth LE
● Zigbee (IEEE 802.15.4)
Zigbee: IEEE 802.15.4 Protocols: RV-C/Modbus/Zigbee 3.0
Touch Screen: 4 inches (480 x 480p)
White backlight with adjustable brightness
Dimension: 181.8 x 86.8 x 42.2 mm (7.16 x 3.42 x 1.66 in)
Installation: Flush mounting Weight: 286 g/0.83 lbs
Color: Black Casing Material: PC+ABS V0
Applicable Place: Indoor Operating Altitude: Less than 2000 m above sea level
Operating Temperature: -20℃~50℃ (-4℉~122℉) Operating Humidity: 0%~95%RH
